Zillion    CCIT detectors    ARGO
Zillion-AJH-FD1-1
DSC02657

ARGO

Features:
> Compact design, small footprint
>Portabledesign, easy to car间 and carry
>Small and large infusion bags can be detected, no need to customize the mold
>She operation in simple and easy to master



Technical parameters

Principle  low-voltage discharge and leakage detection
Application sauce bag, udon noodles, tofu, drinks, milk bag, laundry detergent bag, etc
Configure  the host machine (including the detection table) and the electrode brush
The range of detection less than 100um,depending on the specific product
Detection bag capacity 50mL to 2000mL
Detection speed 15 seconds per bag (a little error during manual operation)
Detection voltage 1kV-1OkV
Operation mode Both hands operate at the same time, the left hand pressure the high voltage switch, the right hand press the trigger switch
Detection sensitivity adjustable (used with detection voltage)
Detection results alarm
Leakage position alarm can help find the leakage hole position
Host size  length (440mm) width (350mm) height (220mm)
Host weight 13 kg
Power supply single-phase AC 100V60 / 50 Hz
Pay attention 1. Do not remove the equipment mechanical panel (protective shell) at will, otherwise there will not be any warranty; 2. Ground the device (grounding wire) when using it
Note: There are customized models with upgraded functions, interested parties please contact directly
